2096214 YG2A14-200VB3XLEAX SICK Straight Female 4 way M12 to Straight Unterminated Connector & Cable 20m
$43.00
- Part Number: 2096214 YG2A14-200VB3XLEAX
- Manufacturer:SICK
- Availability: Out of stock
- Estimated Lead Time: 4-6week
- Condition: Brand New
- Warranty :12 months
Available on backorder
| Connection type head A | Female connector, M12, 4-pin, angled, A-coded | ||||||||
| Connection type head B | Flying leads | ||||||||
| Locking plug connector | Screw connection | ||||||||
| Connector material | TPU | ||||||||
| Connector color | Black | ||||||||
| Locking nut material | Zinc die-cast, nickel-plated | ||||||||
| Seal material | FKM | ||||||||
| Tightening torque | 0.6 Nm | ||||||||
| Width across flats | 13 | ||||||||
| Cable | 20 m, 4-wire, PVC | ||||||||
| Jacket material | PVC | ||||||||
| Jacket color | Gray | ||||||||
| Cable diameter | 5 mm | ||||||||
| Conductor cross section | 0.34 mm² | ||||||||
| Shielding | Unshielded | ||||||||
| |||||||||
| Nominal voltage, cable | 300 V AC | ||||||||
| Test voltage, cable | 2,000 V AC | ||||||||
| |||||||||
| Rated impulse voltage | 2.5 kV | ||||||||
| Current loading | 4 A | ||||||||
| Signal type | Sensor/actuator cable | ||||||||
| Application | Zones with chemicals Uncontaminated zones | ||||||||
| Authorizations | CE UL | ||||||||
| UL File No. | E335179 | ||||||||
| Enclosure rating | IP65 / IP66K / IP67 | ||||||||
| |||||||||
| Contamination rating | 3 | ||||||||
| Insulation resistance | 100 MΩ | ||||||||
| Overvoltage category | III | ||||||||
| Specific insulation resistance | 30 mΩ | ||||||||
| Thermal resistance, piping | Flame retardant according to UL 1581 VW1 / CSA FT1 | ||||||||
| Weight | 2 kg |
|---|---|
| Dimensions | 30 × 30 × 15 cm |
